Reflecting on the benefits of VRF

Such has been the growth in VRF air conditioning in the UK that it is now the second largest sector in this market. Recent figures from BSRIA value the VRF market at £87 million a year — about 17% of the market. In achieving that second place, VRF has overtaken chillers in value terms and is also making ground on the traditional commercial split sector.

23 Daikin VRV-II heat-recovery condensing units supplied by Space Airconditioning for a refurbishment project in central London serve 245 ducted fan-coils.

Space Airconditioning adds value to Daikin VRV system

To aid installation on site of Daikin VRV-II air conditioning equipment providing 975 kW of cooling for refurbishing a 1960s building in London, distributor Space Airconditioning supplied a range of extra services.

Powerful approach to control for hotel air conditioning

A programmable logic controller for Mitsubishi Electric’s City Multi air-conditioning range allows easy automatic interlocking, with multiple units controlled through card-key readers, passive infra-red devices, window contacts and over-ride switches. This PLC system links to the G50 and baby G50 controllers and is designed for applications such as hotels where it has been difficult to accurately control individual units in each room because of the localised setting of each guest.

Now famous as the cricket ground where England won the Ashes this summer, the Brit Oval uses Sanyo VRF air conditioning in the new OCS stand.

The Brit Oval is bowled over by Sanyo

The pressures placed on the cricket teams in the final match of the Ashes series at the Oval this summer were reflected in the demands placed on the air-conditioning system for the new £25 million OCS stand.

VRF unit
Commercial buildings up to nine storeys high are within the capabilities of Toshiba Air Conditioning’s SHRM2 VRF system.

VRF air conditioning reaches new heights

Toshiba’s latest VRF range is a 3-pipe heat-recovery system. The SHRM2 series offers 22 to 84 kW of cooling from a single inverter-driven system and up to 95 kW of heating. R410A is the refrigerant.

Tulip Hotel
Daikin VRVII heat-recovery air conditioning installed in the Tulip Hotel at North Harbour, Portsmouth, enables heat loads to be balanced and energy consumption reduced.

Daikin Heat-recovery VRV serves Portsmouth Tulip Inn

The popularity of Daikin’s VRV air conditioning in hotels is reflected by the installation in the Tulip Inn at North Harbour, Portsmouth. Golden Tulip Hotels are regarded as superior-quality establishments. This hotel has 108 guest rooms on five floors, complemented by quiet lounge areas, stylish and contemporary restaurant and bars, three well equipped meeting rooms and a spacious reception.

Leakage testing
The air tightness of buildings is addressed by the New Part L of the Building Regulations. If a building fails to satisfy the National Calculation Methodolgy, reducing air leakage is one of the few remedial measures possible.

Understanding the new Building Regulations

Changes to the Building Regulations could require the energy performance of commercial buildings to be reduced by 28% compared with the 2002 regulations. NIGEL POTTER discusses the philosophy behind the latest regulations.

School kids
Let’s play at being engineers — Ant Wilson stimulates enthusiasm in young children by letting them dress up.

Introducing school children to the excitement of engineering

If pupils at school do not know about building-services engineering, how can they express an interest in joining the profession? ANT WILSON shares his experiences in taking the initiative and making them aware of the excitement of engineering.

Lighting the workplace well

HARRY BARNITT argues that following standard lighting guidance results in poor installations. One of the main reasons is the failure to put any light on the ceiling.

Controlling office lighting for effectiveness and efficiency

NEIL JONES describes how lighting control can cut an organisation’s fuel bill and also deliver other key business benefits.

Plug-and-play connection systems such as Wieland’s Gesis range, provide important safety features such as making it impossible to mismatch different connectors.

Increasing the speed of light

Plug-and play-connectivity has changed installation practices for lighting, so that projects can be speeded up up enormously, as MARK REDFERN explains.

Flexible busbar
By providing power distribution and built-in tap-off points for lighting fittings on Canalis KDP flexible busbar trunking in lengths up to 192 m, Schneider Electric claims to offer all the benefits of a bespoke prefabricated system with none of the drawbacks.

Schneider Electric rethinks the installation of lighting systems

More than halving the time to install a lighting system above a suspended ceiling with the same material cost as traditional materials is what Schneider Electric claims to have achieved with a new flexible busbar system.

The beginning and end of energy-efficient lighting — as staff arrive and leave Staples outlets equipped with Hager’s Tebis TS system they switch the lighting on and off, using a secure key switch.

Lighting is a Staples energy saver

An energy-saving lighting-control system for nearly 140 Staples retail outlets nationwide is being provided using Hager’s Tebis TS bus system. The system is also being used to control radiant heaters.

Thomas Cook
Nationwide management and maintenance of lighting for Thomas Cook travel shops is provided by Parkersell.

Lighting up the best known travel brand

Travel specialist Thomas Cook has re-appointed Parkersell (Lighting & Electrical) Services to manage and maintain lighting and signage throughout its UK travel shops. The work covers over 600 retail outlets. Parkersell’s remit also includes electrical testing and inspection services to ensure that all the travel shops comply with current legislation.

As part of the relighting of this church in the City of London during a 6-year renovation programme, Eaton’s Studio 3 lighting controls have been incorporated.

City church seen in a new light

An improved lighting scheme controlled by Eaton’s Studio 3 lighting controls has contributed to restoring the glory of the only Wren church in the City of London.

A good mix of uplight and downlight in a refurbished office building in London is achieved using Whitecroft’s Vector fittings.

Vector luminaires provide lighting with magnitude and direction

Whitecroft Lighting has supplied a range of luminaires, including direct/indirect Vector fittings and Mirage downlighters, for a refurbished office block in London.

Long life and high light output in high spaces — Chalmor’s Brilliance luminaires.

Chalmor demonstrates Brilliance in lighting

Chalmor’s Brilliance high-output, energy-efficient light fitting is designed to offer low maintenance with an operating life of 20 000 h before relamping is required. Standard models come with a 5-year warranty on control gear.

Combining aesthetics and robust construction — Thorn’s Concavia range of high-bay luminaires can be used with a variety of lamp types.

High-bay perfection

Thorn’s Concavia range of high-bay lighting fittings is suitable for everything from retail and commercial premises to heavy industrial buildings. It combines aesthetics with robust construction. There are three sizes of luminaires — small, large and extra large.

Gresham Street
With floor heights restricted in this building by the need to stay below the sightline of St Paul’s Cathedral, Whitecroft Lighting supplied around 10 000 special compact fluorescent luminaires requiring an installed depth of just 80 mm.

Compact fluorescent luminaires are small but perfectly formed

Some 10 000 special compact fluorescent luminaires were supplied by Whitecroft Lighting for one of the biggest speculative developments in the City of London. Working with consulting engineers Faber Maunsell, Whitecroft developed a bespoke luminaire to resolve issue of high-volume air handling by designing a bypass system to reduce installed costs at 30 Gresham Street. The luminaires were installed by Emcor Drake & Scull.

British Library
The staged replacement and upgrading of the lighting-control system in the British Library has been achieved with a system based on the European Installation Bus and installed by Andromeda Telematics.

New lighting controls for British Library

To replace and upgrade its existing lighting-control system, the British Library has opted for a system based on the European Installation Bus from Andromeda Telematics.

RIDI Lighting’s EBD range of downlighters has been totally revised.

Downlighter range receives complete makeover

RIDI Lighting has launched a totally revised range of downlighters. The EBD range is available in five diameters from 150 to 340 mm with compact fluorescent lamps from 11 to 57 W. Various depths are offered, including a very shallow unit only 60 mm deep.

Bailey and Green
(left) Cal Bailey - The need for a culture change
(right) Phil Green - Supporting on-site operatives .

The business case for a contractor of off-site manufacture

Developing off-site manufacture is a vital element in the future development of contractor NG Bailey, and it brings major benefits to the construction industry — as CAL BAILEY and PHIL GREEN explained to Ken Sharpe

Make sure you ask the right questions of your supplier in order to get a fully functioning system that is guaranteed, has no cost or time overruns and needs minimal input from you

Avoiding the hidden costs of packaged plant

Rick Plummer looks at the not-so-obvious costs that can scupper the most carefully planned budget for heating plant and explains how to avoid them.

The speed and efficiency of installation is greatly improved by the use of 3D modelling and is brought to full potential by off-site manufacture.

The scope and benefits of packaged plant rooms

Manufacturing plant rooms off site offers a range of benefits, which are increasing all the time

— as STEVE COOPER explains.

Over 250 services modules made by MEP Solutions halved installation time for three new offices for BSkyB.

Pre-fabrication doubles installation speed at BSkyB

Installation time for services for a new office development for British Sky Broadcasting has been halved by using building-services modules designed by MEP Solutions and made off site. The prefabricated modules connect some 60 to 70% of the services on each floor. The rest are piped in the traditional method because of structural considerations and layout.

Cable tray
Over 30 km of Cablofil wire mesh cable trays is being incorporated into prefabricated service units for Manchester Royal Infirmary.

Hospital prefabricated service units utilise wire-mesh cable tray

Cablofil wire-mesh cable trays are being used in modular pre-fabricated services units for Manchester Royal Infirmary, or the Manchester Joint Hospital as it is known.

Pump set
Configurable HVAC pump packages from Armstrong Holden Brooke Pullen achieve the benefits of bespoke systems with lower cost and shorter lead times.

Packaged pump range delivers prefabrication benefits

Armstrong Holden Brooke Pullen now offers configurable HVAC pumping packages that reduce installation time on site and enable designers to select an effective system solution without the high costs and longer lead times associated with bespoke systems.

Boiler rig
Prefabricated boiler rigs from Geminox can accommodate up to eight boilers to provide a maximum output of 420 kW.

Prefabricated boiler rigs

Geminox now offers prefabricated boiler plant in the UK following success in partner countries.

Building for the future — part 1

Skills shortages and skills gaps encapsulate the two greatest concerns of the building-services sector in its need to ensure adequate capacity and capability to deliver projects in the future. Let’s face it, the average age of people in the industry is increasing — and one of the main reasons is that younger people are not entering the industry.

Building for the future — part 2

How many people are there with misgivings about the sort of examinations that children at school and students take? Many people wonder about the worth of media studies, psychology, leisure and tourism and a whole range of other courses.

Revised Building Regulations to arrive two years early

New measures to make buildings more energy efficient will save a million tonnes of carbon a year by 2010, according to an announcement from the Office of the Deputy Prime Minister and DEFRA last month (September).


New college shows the way in teaching

The architectural design for this newly completed futuristic building for Stephenson College in Leicestershire has been shortlisted for ‘Building of the year’ in the ProCon Leicestershire Property Awards.

Thermal Transfer shares in European Construction Industry award

Mechanical contractor Thermal Transfer is part of an alliance team awarded the European Construction Industry ACTIVE ‘Best project of the year award’.


Space Air motor cyclist regains championship lead

Motorcyclist Jay Fernandez, sponsored by air-conditioning distributor Space Air, is back in the lead of the 2005 MRO SuperTwins Champions after two tough rounds at Knockhill and Cadwell Place.


White Young Green provides design services for college

Design services for this £9 million development at Accrington & Rossendale College are being provided by White Young Green. It has been necessary to pay particular attention to the steeply sloping site, a phased construction programme and keeping the site fully operational.

Daikin to open new headquarters

Daikin Airconditioning UK is moving to new state-of-the-art office in Weybridge. As a result, the next few months will see regional offices in Woking, Redhill and Heston integrated into the new premises.

Julian Amey
Welcoming the new Part L — CIBSE’s chief executive Julian Amey.

CIBSE prepares to build on Part L

CIBSE has welcomed the publication of the new Part L of the Building Regulations, which contains many of the institution’s suggestions from the original consultation in 2004. CIBSE expresses disappointment that some measures relating to improving existing dwellings have been dropped, but supports ODPM in its efforts to drive up the energy efficiency of non-domestic buildings.

Major Projects Agreement brings benefits to Terminal 5

The Major Projects Agreement (MPA) has had a positive impact on the Terminal 5 project at Heathrow Airport, according to a survey by independent auditors Baker Mallett.

Jim Moore
Vaillant Group’s managing Jim Moore looks forward to an 80% boost in capacity in the UK.

Vaillant boosts capacity to meet growth markets

Vaillant Group is boosting capacity at its UK assembly plant at Belper in Derbyshire by 80% to meet soaring demand for high-efficiency boilers. The facility will now operate 24 h a day, six days a week, and employ 60 more staff.

BEST raises GCSE selection criteria for craft apprentices

BEST (Building Engineering Services Training) has taken steps to encourage only the highest calibre learners to apply for the limited places offered by employers. The company is a leading training provider for the HVAC&R and plumbing industries and has raised its entrance criteria for craft apprenticeships.

Closing down — York International’s air-conditioning factory at Basildon is to be closed down as part of a major strategic restructuring effort.

York’s Basildon factory to be closed down in restructuring

York International’s air-conditioning factory at Basildon is to be closed as part of a major strategic restructuring across York Europe, Middle-East and Africa. The news closely following the announcement by Johnson Controls that it is to Acquire York International for about $3.2 billion.

To provide natural ventilation and prevent overheating in this new mathematics block at a school in Dorset, Monodraught Windcatcher units have been installed in each classroom.

School maths department counts on natural ventilation

In response to Government policy to exploit natural, energy-saving solutions in schools, ventilation for classrooms in the new mathematics block at a school in Dorset is provided by Monodraught Windcatcher natural-ventilation units.

The specialist cooling requirements of food-preparation areas in Morrisons supermarkets are being met by Qualitair’s QLC range of low-temperature ceiling cassettes.

Qualitair controls ‘Street’ temperatures in Morrisons supermarkets

As part of the major refurbishment and conversion programme of Morrisons supermarkets, Qualitair QLC low-temperature ceiling cassettes are being installed in the Market Street area of each store. These areas consist of specialist food counters such as a fishmonger, baker and greengrocer. The concept is part of the company’s strategy to offer customers food that has been freshly prepared in the store.

Evaporative cooling using four Breezair units has reduced temperature in the Telford factory of Aga from over 30°C to less than 25°C.

Evaporative cooling overcomes Aga’s overheating problem

Aga, which makes the cast-iron Aga cooker, has overcome the problem of temperatures in its factory at Telford exceeding 30°C by installing a Breezair evaporative air-cooling system. It has reduced the temperature to less than 25°C.

heat exchanger
The precise controllability of Spirax Sarco plate heat exchangers compared to shell-and-tube heat exchangers is reducing fuel bills by £5000 a year at a hospital in Crewe.

New heat exchanger improves hospital energy performance

Replacing four shell-and-tube heat exchangers with plate heat exchangers at Leighton Hospital in Crewe is expected to achieve energy savings of more than £5000 a year. The savings come mainly form improved control. Ken Hardy, estates manager at the hospital, says, ‘The new units are saving energy, because they have eliminated the frequent [temperature] overshoots we used to get.’ Efficiency has been improved by over 5%.

Valves to control hot- and cold-water services in this eye-catching hotel in Cambridge were supplied by Oventrop.

Oventrop sets the temperature in Cambridge hotel

Valves to control domestic hot water and other water services in a hotel with an award-winning exterior were supplied by Oventrop for mechanical-services contractor Bower Fuller. The Oventrop valves have been installed throughout the 120-bedroom, 6-storey Travelodge in Cambridge.

With about half the size and weight of other air-conditioning units of similar capacity, these Toshiba units were installed at Lakeside in Essex without needing a crane.

Air-conditioning units take the weight off an installer’s mind

Air-conditioning units with the cooling capacity of units that are normally twice the size and weight have been installed in the extended and refurbished River Island store at Lakeside in Essex. The compact Toshiba 12.5 kW digital inverter split systems were installed by Metainy.

CHP in environmental-sustainability showcase

Combined heat and power is among a range of technologies installed at Solaris, a regional centre of excellence in environmental sustainability in Blackpool.

In a drive towards greater efficiency in its schools, Glasgow City Council has invested in Schneider Electric’s Transparent Integrated Building System for its newly built Haghill Primary School.

School learns the lessons of integrated building systems

The intelligent integration of services in the new Haghill Primary School & Community Sports Centre in Glasgow is generating substantial energy savings. This is one of the first new schools to be built as part of a programme of work involving over 200 new and refurbished schools.

Boiler room
As part of an ongoing and environmentally aware long-term maintenance programme, six Andrews Maxxflo condensing storage water heaters have been installed on the Streatham campus of the university of Exeter.

Condensing water heaters are part of university’s environmental plan

As part of an investment programme that includes upgrading and replacing current facilities as part of a long-term maintenance programme, six Andrews Maxxflo condensing storage water heaters have been installed in various locations on the Streatham Campus of the University of Exeter. They join numerous other Andrews water-heating and boiler installations already operating on the site.
